90B05SLT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP ON OFF SPST 5 Flush Slide 0.15A 30VDC PC Pins 2000Cycles/SwitchCycles 2.54mm Thru-Hole Tube
PDF
/
Inventory: 6452
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height Above Board 0.195 4.95mm
Length 0.570 14.48mm
Technical
Actuator Level Flush, Recessed
Washable Yes
Mechanical Life 2,000 Cycles
Max Voltage Rating (DC) 30V
Throw Configuration SPST
Electrical Life 2,000 Cycles
Max Current Rating 150mA
Circuit SPST
Actuator Type Slide (Standard)
Termination Style PC Pin
Contact Finish Gold
Current Rating 25mA
Orientation Straight
Pitch 0.100 2.54mm Full
Current Rating (Amps) 25mA
Voltage - Rated DC 24V
Voltage - Rated 24VDC
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Positions 5
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Position Identification Line, Tape Seal
Series 90B
Published 2010
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Body Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 18 Weeks
