78J04RAT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP N.O./N.C. SPDT 4 Raised Slide 0.15A 30VDC PC Pins 2000Cycles/SwitchCycles 2.54mm Thru-Hole Tube
PDF
/
Buying Options
Total Price: USD $20.48
Unit Price: USD $20.475988
≥1 USD $20.475988
≥204 USD $8.170177
≥504 USD $7.897094
≥996 USD $7.763178
Inventory: 7084
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Through Hole
Mounting Type Through Hole, Right Angle
Body Material Plastic
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2010
Series 78
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
ECCN Code EAR99
Number of Positions 4
Voltage - Rated 30VDC
Voltage - Rated DC 30V
Pitch 0.100 2.54mm Full
Orientation Straight
Current Rating 150mA
Contact Finish Gold
Termination Style PC Pin
Actuator Type Slide (Standard)
Circuit SPDT
Max Current Rating 150mA
Electrical Life 10,000 Cycles
Max Voltage Rating (DC) 30V
Mechanical Life 2,000 Cycles
Switch Type SLIDE DIP SWITCH
Washable No
Actuator Level Raised
Dimensions
Length 0.880 22.35mm
Height Above Board 0.380 9.64mm
Compliance
RoHS Status RoHS Compliant
