76RSB03SLT

Grayhill Inc.
RoHS
RoHS RoHS compliant
Package /
Category Switches / DIP Switches
Description Switch DIP ON OFF SPST 3 Recessed Rocker 0.15A 30VDC PC Pins 2000Cycles/SwitchCycles 2.54mm Thru-Hole Tube
PDF
/
Inventory: 4751
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Number of Positions 3
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Voltage - Rated 30VDC
Voltage - Rated DC 30V
Current Rating (Amps) 150mA
Pitch 0.100 2.54mm Full
Orientation Straight
Current Rating 150mA
Contact Finish Gold
Termination Style PC Pin
Actuator Type Rocker
Circuit SPST
Max Current Rating 150mA
Electrical Life 2,000 Cycles
Throw Configuration SPST
Max Voltage Rating (DC) 30V
Mechanical Life 2,000 Cycles
Washable Yes
Actuator Level Flush, Recessed
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Position Identification Line, Tape Seal
Series 76
Published 2015
Packaging Tube
Operating Temperature -40°C~85°C

Dimensions

Length 0.380 9.65mm
Height Above Board 0.292 7.41mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant

Physical

Body Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 16 Weeks
