KAR10LHGT
RoHS
/
Package /
Category Switches / DIP Switches
Description
SWITCH PIANO DIP SPST 25MA 24V
PDF
/
Buying Options
Total Price: USD $3.49
Unit Price: USD $3.492314
≥1 USD $3.492314
≥198 USD $1.3943
≥504 USD $1.347035
≥1008 USD $1.324716
Inventory: 6552
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.293 7.45mm
Body Height 7.4422mm
Length 1.090 27.69mm
Technical
Actuator Level Raised
Washable Yes
PCB Hole Count 20
Number of Switch Sections 10
Mechanical Life 2,000 Cycles
Dielectric Withstanding Voltage 500VAC V
Contact Current(DC)-Max 0.025A
Contact Resistance 0.1mOhm
Circuit SPST
Actuator Type Piano
Body Breadth 8.9916 mm
Termination Style PC Pin
Contact Finish Gold
Current Rating 25mA
Pitch 0.100 2.54mm Full
Voltage - Rated DC 24V
Voltage - Rated 24VDC
Number of Positions 10
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Process Sealed
Series KAR
Published 2006
Packaging Tube
Operating Temperature -30°C~85°C
Physical
Terminal Material BRASS
Body Material Polyphenylene Sulfide (PPS)
Insulation Material POLYPHENYLENE SULPHIDE
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Material Copper Alloy
