KAN1104RR

E-Switch
RoHS
RoHS RoHS compliant
Package /
Category Switches / DIP Switches
Description SWITCH SLIDE DIP SPST 25MA 24V
PDF
/
Inventory: 9365
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Contact Material Copper Alloy
Mount Surface Mount
Mounting Type Surface Mount
Insulation Material POLYPHENYLENE SULPHIDE
Housing Material POLYPHENYLENE SULPHIDE
Body Material Polyphenylene Sulfide (PPS)
Actuator Material Nylon
Terminal Material BRASS

Technical

Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2006
Series KAN
Feature Tape Seal
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
ECCN Code EAR99
Number of Positions 4
Voltage - Rated 24VDC
Voltage - Rated DC 24V
Pitch 0.050 1.27mm Half
Orientation Straight
Terminal Pitch 1.27mm
Current Rating 25mA
Contact Finish Gold
Termination Style Gull Wing
Actuator Type Slide (Standard)
Circuit SPST
Contact Resistance 50mOhm
Insulation Resistance 100000000Ohm
Contact Current(DC)-Max 0.025A
Dielectric Withstanding Voltage 500VRMS V
Electrical Life 2,000 Cycles
Max Voltage Rating (DC) 24V
Mechanical Life 2,000 Cycles
Switch Type SLIDE DIP SWITCH
Actuator Color WHITE
Washable Yes
Actuator Level Flush, Recessed

Dimensions

Length 0.248 6.31mm
Body Height 1.651mm
Actuator Length 0m
Height Above Board 0.063 1.60mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
