KAJ06LAGT

E-Switch
RoHS
/
Package /
Category Switches / DIP Switches
Description Slide (Standard) KAJ 6 Through Hole Dip Switch 0.165 4.20mm 0.025A 24V 0.05mOhm
PDF
/
Buying Options
Total Price: USD $1.87
Unit Price: USD $1.866944
≥1 USD $1.866944
≥198 USD $0.745727
≥495 USD $0.720782
≥990 USD $0.707653
Inventory: 1721
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Height Above Board 0.165 4.20mm
Length 0.600 15.24mm

Technical

Body Color BLACK
Actuator Level Raised
Washable No
Actuator Color WHITE
PCB Hole Count 12
Mechanical Life 2,000 Cycles
Electrical Life 2,000 Cycles
Dielectric Withstanding Voltage 500VRMS V
Contact Voltage(DC)-Max 24V
Contact Current(DC)-Max 0.025A
Insulation Resistance 100000000Ohm
Contact Resistance 0.05mOhm
Circuit SPST
Actuator Type Slide (Standard)
Body Breadth 5.9944 mm
Termination Style PC Pin
Contact Finish Gold
Pitch 0.100 2.54mm Full
Current Rating (Amps) 25mA
Voltage - Rated 24VDC
Number of Positions 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series KAJ
Published 2002
Packaging Tube
Operating Temperature -40°C~85°C

Physical

Terminal Material BRASS
Body Material Polyphenylene Sulfide (PPS)
Housing Material POLYPHENYLENE SULPHIDE
Insulation Material POLYPHENYLENE SULPHIDE
Mounting Type Through Hole
Mount Through Hole
Contact Material Copper Alloy
