KAC10LGGT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SWITCH PIANO DIP SPST 25MA 24V
PDF
/
Buying Options
Total Price: USD $5.66
Unit Price: USD $5.657286
≥1 USD $5.657286
≥192 USD $2.258188
≥496 USD $2.18204
≥992 USD $2.145279
Inventory: 1986
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Above Board 0.201 5.10mm
Body Height 5.9944mm
Length 1.055 26.80mm
Technical
Actuator Angle 20 deg
Actuator Level Raised
Washable No
Number of Switch Sections 10
Mechanical Life 2,000 Cycles
Electrical Life 2,000 Cycles
Dielectric Withstanding Voltage 500VAC V
Contact Voltage(DC)-Max 24V
Contact Current(DC)-Max 0.025A
Contact Resistance 0.05mOhm
Circuit SPST
Actuator Type Piano
Termination Style Gull Wing
Contact Finish Gold
Pitch 0.100 2.54mm Full
Current Rating (Amps) 25mA
Voltage - Rated 24VDC
Number of Positions 10
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series KAC
Published 2012
Packaging Tube
Operating Temperature -20°C~85°C
Physical
Terminal Material BRASS
Center Contact Material COPPER
Mounting Feature SURFACE MOUNT-RIGHT ANGLE
Surface Mount NO
Mounting Type Surface Mount, Right Angle
Supply Chain
Factory Lead Time 11 Weeks
