210-12ESFD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Slide (Standard) 210 12 Through Hole Dip Switch 3.8mm 0.1A 20V -40C~85C
PDF
/
Buying Options
Total Price: USD $1.49
Unit Price: USD $1.49408
≥1 USD $1.49408
≥195 USD $0.596057
≥495 USD $0.576363
≥1005 USD $0.567173
Inventory: 4100
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.204 5.18mm
Body Height 3.8mm
Length 1.258 31.95mm
Technical
Actuator Level Raised
Washable No
Number of Switch Sections 12
Switch Type SLIDE DIP SWITCH
Electrical Life 1,000 Cycles
Contact Voltage(DC)-Max 20V
Sealing BOTTOM SEALED
Contact Current(DC)-Max 0.1A
Circuit SPST
Actuator Type Slide (Standard)
Body Breadth 6.7 mm
Termination Style PC Pin
Contact Finish Gold
Pitch 0.100 2.54mm Full
Current Rating (Amps) 100mA
HTS Code 8536.50.90.65
Voltage - Rated 20VDC
Terminal Finish Tin (Sn)
Number of Positions 12
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Epoxy Sealed Terminals
JESD-609 Code e3
Series 210
Published 2016
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount NO
Mounting Type Through Hole
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 8 Weeks
