206-8E
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP OFF ON SPST 8 Extended Slide 0.05A 24VDC PC Pins 2.54mm Thru-Hole Tube
PDF
/
Inventory: 6602
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Through Hole
Body Material Plastic
Technical
Operating Temperature -55°C~85°C
Packaging Tube
Published 2010
Series 206
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Positions 8
Voltage - Rated 24VDC
Current Rating (Amps) 50mA
Pitch 0.100 2.54mm Full
Contact Finish Gold
Termination Style PC Pin
Actuator Type Slide (Standard)
Circuit SPST
Electrical Life 10,000 Cycles
Washable No
Actuator Level Raised
Dimensions
Length 0.886 22.50mm
Height Above Board 0.434 11.02mm
Compliance
RoHS Status RoHS Compliant
