206-7RA
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP OFF ON SPST 7 Raised Slide 0.05A 24VDC PC Pins 2.54mm Thru-Hole Tube
PDF
/
Inventory: 10020
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Through Hole, Right Angle
Surface Mount NO
Mounting Feature THROUGH HOLE-RIGHT ANGLE
Body Material Plastic
Technical
Operating Temperature -55°C~85°C
Packaging Tube
Published 2009
Series 206RA
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Number of Positions 7
Voltage - Rated 24VDC
HTS Code 8536.50.90.65
Current Rating (Amps) 50mA
Pitch 0.100 2.54mm Full
Contact Finish Gold
Termination Style PC Pin
Actuator Type Slide (Standard)
Circuit SPST
Contact Current(DC)-Max 0.05A
Contact Voltage(DC)-Max 24V
Electrical Life 10,000 Cycles
Switch Type SLIDE DIP SWITCH
Number of Switch Sections 7
Washable No
Actuator Level Raised
Dimensions
Length 0.786 19.96mm
Body Height 10.16mm
Height Above Board 0.400 10.16mm
Compliance
RoHS Status RoHS Compliant
