206-216RAS
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP OFF ON DPST 6 Raised Slide 0.05A 24VDC PC Pins 2.54mm Thru-Hole Tube
PDF
/
Buying Options
Total Price: USD $2.93
Unit Price: USD $2.92908
≥1 USD $2.92908
≥195 USD $1.169794
≥495 USD $1.130407
≥1005 USD $1.110713
Inventory: 9668
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.400 10.16mm
Length 1.286 32.66mm
Technical
Actuator Level Raised
Washable No
Number of Switch Sections 6
Switch Type SLIDE DIP SWITCH
Electrical Life 10,000 Cycles
Contact Voltage(DC)-Max 24V
Sealing BOTTOM SEALED; TOP TAPE SEALED
Contact Current(DC)-Max 0.05A
Circuit DPST
Actuator Type Slide (Standard)
Body Breadth 9.78 mm
Termination Style PC Pin
Contact Finish Gold
Pitch 0.100 2.54mm Full
Current Rating (Amps) 50mA
Voltage - Rated 24VDC
Terminal Finish TIN
Number of Positions 6
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
JESD-609 Code e3
Series 206RA
Published 2009
Packaging Tube
Operating Temperature -55°C~85°C
Physical
Body Material Plastic
Mounting Feature THROUGH HOLE-RIGHT ANGLE
Surface Mount NO
Mounting Type Through Hole, Right Angle
Supply Chain
Factory Lead Time 8 Weeks
