206-122ST
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP OFF ON SPDT 2 Raised Slide 0.05A 24VDC PC Pins 2.54mm Thru-Hole Tube
PDF
/
Buying Options
Total Price: USD $2.6
Unit Price: USD $2.596833
≥1 USD $2.596833
≥10 USD $2.449841
≥100 USD $2.311168
≥500 USD $2.180352
≥1000 USD $2.056937
Inventory: 1120
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.334 8.48mm
Body Height 7.6mm
Length 0.486 12.34mm
Technical
Actuator Level Raised
Washable Yes
Number of Switch Sections 2
Switch Type SLIDE DIP SWITCH
Electrical Life 10,000 Cycles
Sealing EPOXY TERMINAL SEALED; TOP TAPE SEALED
Contact Current(DC)-Max 0.05A
Circuit SPDT
Actuator Type Slide (Standard)
Body Breadth 9.78 mm
Termination Style PC Pin
Contact Finish Gold
Pitch 0.100 2.54mm Full
Current Rating (Amps) 50mA
HTS Code 8536.50.90.65
Voltage - Rated 24VDC
Number of Positions 2
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Epoxy Sealed Terminals, Tape Seal
JESD-609 Code e4
Series 206
Published 2014
Packaging Tube
Operating Temperature -55°C~85°C
Physical
Body Material Plastic
Surface Mount NO
Mounting Type Through Hole
Supply Chain
Factory Lead Time 8 Weeks
