195-6MS
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP OFF ON SPST 6 Piano 0.05A 24VDC PC Pins 2.54mm Thru-Hole Tube
PDF
/
Inventory: 1832
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.311 7.90mm
Body Height 7.9mm
Length 0.686 17.42mm
Technical
Actuator Level Raised
Washable No
Number of Switch Sections 6
Electrical Life 2,000 Cycles
Dielectric Withstanding Voltage 500VAC V
Contact Voltage(DC)-Max 24V
Sealing EPOXY TERMINAL SEALED
Contact Current(DC)-Max 0.05A
Insulation Resistance 1000000000Ohm
Contact Resistance 0.5mOhm
Circuit SPST
Actuator Type Piano
Body Breadth 9.78 mm
Termination Style PC Pin
Contact Finish Tin
Pitch 0.100 2.54mm Full
Current Rating (Amps) 50mA
Additional Feature SHIP AT OFF POSITION
Voltage - Rated 24VDC
Number of Positions 6
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Epoxy Sealed Terminals
JESD-609 Code e3
Series 195
Published 2008
Packaging Tube
Operating Temperature -40°C~85°C
Physical
End Contact Plating TIN
End Contact Material COPPER ALLOY
Center Contact Material COPPER ALLOY
Center Contact Plating TIN
Body Material Plastic
Mounting Feature THROUGH HOLE-STRAIGHT
Surface Mount NO
Mounting Type Through Hole, Right Angle
Supply Chain
Factory Lead Time 8 Weeks
