SDA12H0KD
RoHS
/
Package DIP
Category Switches / DIP Switches
Description
DIP Switches / SIP Switches FLUSH ACT 12 POS
PDF
/
Buying Options
Total Price: USD $4.25
Unit Price: USD $4.247232
≥1 USD $4.247232
≥196 USD $1.694954
≥504 USD $1.638499
≥994 USD $1.610928
Inventory: 6507
Minimum: 1
-
+
Technical Details
Technical
Electrical Life 1,000 Cycles
Circuit SPST
Actuator Type Slide (Standard)
Termination Style PC Pin
Contact Finish Gold
Current Rating 25mA
Terminal Pitch 2.54mm
Pitch 0.100 2.54mm Full
Current Rating (Amps) 25mA
Voltage - Rated DC 24V
Voltage - Rated 24VDC
Min Operating Temperature -20°C
Max Operating Temperature 85°C
Number of Positions 12
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series SDA
Published 2001
Packaging Tube
Operating Temperature -20°C~85°C
Actuator Level Flush, Recessed
Washable No
Mechanical Life 1,000 Cycles
Max Voltage Rating (DC) 50V
Throw Configuration SPST
Number of Poles 12
Physical
Body Material Polyphthalamide (PPA)
Package / Case DIP
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 9 Weeks
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Height Above Board 0.189 4.80mm
Length 1.279 32.50mm
