SD08H0SBD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SWITCH SLIDE DIP SPST 100MA 25V
PDF
/
Buying Options
Total Price: USD $3.78
Unit Price: USD $3.779839
≥1 USD $3.779839
≥200 USD $1.462571
≥500 USD $1.411368
≥1000 USD $1.386422
Inventory: 1414
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height Above Board 0.155 3.94mm
Actuator Length 0m
Length 0.858 21.80mm
Technical
Actuator Level Flush, Recessed
Washable No
Mechanical Life 2,000 Cycles
Max Voltage Rating (DC) 25V
Electrical Life 2,000 Cycles
Max Current Rating 100mA
Circuit SPST
Actuator Type Slide (Standard)
Termination Style Gull Wing
Contact Finish Gold
Current Rating 100mA
Terminal Pitch 2.54mm
Orientation Straight
Pitch 0.100 2.54mm Full
Voltage - Rated DC 25V
Voltage - Rated 25VDC
Number of Positions 8
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series SD
Published 2011
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Actuator Material Nylon
Body Material Polyphthalamide (PPA)
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 13 Weeks
