BPA08RK

C&K
RoHS
/
Package /
Category Switches / DIP Switches
Description SWITCH PIANO DIP SPST 100MA 5V
PDF
/
Buying Options
Total Price: USD $4.25
Unit Price: USD $4.247232
≥1 USD $4.247232
≥200 USD $1.694954
≥500 USD $1.638499
≥1000 USD $1.610928
Inventory: 8225
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant

Dimensions

Height Above Board 0.287 7.30mm
Actuator Length 2.1mm
Length 0.878 22.30mm

Technical

Actuator Level Raised
Washable Yes
Mechanical Life 1,000 Cycles
Max Voltage Rating (DC) 24V
Electrical Life 1,000 Cycles
Max Current Rating 100mA
Contact Resistance 50mOhm
Circuit SPST
Actuator Type Piano
Termination Style PC Pin
Contact Finish Tin
Current Rating 100mA
Terminal Pitch 2.54mm
Orientation Straight
Pitch 0.100 2.54mm Full
Voltage - Rated DC 5V
Voltage - Rated 5VDC
Number of Positions 8
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series BPA
Published 2003
Packaging Tube
Operating Temperature -20°C~85°C

Physical

Actuator Material Polybutylene
Body Material Polyphenylene Sulfide (PPS)
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Gold, Tin
Contact Material Phosphor Bronze
