BPA08B

C&K
RoHS
RoHS RoHS compliant
Package DIP
Category Switches / DIP Switches
Description SWITCH PIANO DIP SPST 100MA 5V
PDF
/
Buying Options
Total Price: USD $2.09
Unit Price: USD $2.0944
≥1 USD $2.0944
≥10 USD $1.97296
≥100 USD $1.79366
≥500 USD $1.554432
≥1000 USD $1.503718
Inventory: 1206
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 14 Weeks

Physical

Contact Material Beryllium Copper
Mount Through Hole
Mounting Type Through Hole, Right Angle
Package / Case DIP
Body Material Polyphenylene Sulfide (PPS)
Actuator Material Polyamide

Technical

Operating Temperature -20°C~85°C
Packaging Tube
Published 2006
Series BPA
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Number of Positions 8
Voltage - Rated 5VDC
Voltage - Rated DC 5V
Pitch 0.100 2.54mm Full
Orientation Straight
Terminal Pitch 2.54mm
Depth 10.25mm
Current Rating 100mA
Contact Finish Gold
Termination Style PC Pin
Actuator Type Piano
Circuit SPST
Contact Resistance 50mOhm
Max Current Rating 100mA
Electrical Life 1,000 Cycles
Max Voltage Rating (DC) 24V
Mechanical Life 1,000 Cycles
Contact Current Rating 25mA
Washable Yes
Actuator Level Raised

Dimensions

Length 0.878 22.30mm
Actuator Length 2.1mm
Height Above Board 0.287 7.30mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
