BPA02B
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Switches / DIP Switches
Description
SWITCH PIANO DIP SPST 100MA 5V
PDF
/
Buying Options
Total Price: USD $1.53
Unit Price: USD $1.5312
≥1 USD $1.5312
≥10 USD $1.48808
≥100 USD $1.26148
≥500 USD $1.17575
≥1000 USD $1.06553
≥3000 USD $0.99205
Inventory: 1158
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height Above Board 0.287 7.30mm
Actuator Length 2.1mm
Length 0.276 7.00mm
Technical
Actuator Level Raised
Washable Yes
Contact Current Rating 25mA
Mechanical Life 1,000 Cycles
Max Voltage Rating (DC) 24V
Electrical Life 1,000 Cycles
Max Current Rating 100mA
Contact Resistance 50mOhm
Circuit SPST
Actuator Type Piano
Termination Style PC Pin
Contact Finish Gold
Current Rating 100mA
Depth 10.25mm
Terminal Pitch 2.54mm
Orientation Straight
Pitch 0.100 2.54mm Full
Voltage - Rated DC 24V
Voltage - Rated 5VDC
Number of Positions 2
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series BPA
Published 2010
Packaging Tube
Operating Temperature -20°C~85°C
Physical
Actuator Material Polyamide
Body Material Polyphenylene Sulfide (PPS)
Package / Case DIP
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 14 Weeks
