PT65501L254
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SWITCH ROTARY DIP BCD 150MA 24V
PDF
/
Buying Options
Total Price: USD $9.04
Unit Price: USD $9.0376
≥1 USD $9.0376
≥10 USD $8.62312
≥100 USD $7.309104
≥500 USD $6.775296
≥1000 USD $6.159366
≥3000 USD $5.707698
Inventory: 1114
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole, Right Angle
Body Material Thermoplastic
Actuator Material Polyamide
Terminal Material BRASS
Technical
Operating Temperature -20°C~70°C
Packaging Tube
Series PT65
JESD-609 Code e3
Feature Sealed - Flux Protection
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Number of Positions 10
Terminal Finish Tin (Sn)
Voltage - Rated 24VDC
Additional Feature O-RING Si RUBBER ACTUATOR SEAL
HTS Code 8536.50.90.20
Current Rating (Amps) 150mA
Pitch 0.100 2.54mm Full
Packing Method TRAY
Orientation Right Angle
Terminal Pitch 2.54mm
Contact Finish Gold
Termination Style PC Pin
Body Breadth 6.5 mm
Actuator Type Rotary with Knob
Circuit BCD
Contact Resistance 0.08mOhm
Contact Current(DC)-Max 0.4A
Sealing MOLDED
Throw Configuration SP10T
Max Voltage Rating (DC) 24V
Mechanical Life 10,000 Cycles
Switch Type ROTARY CODED SWITCH
Contact Timing BREAK-BEFORE-MAKE
Index Angle 36 deg
Number of Switch Sections 1
PCB Hole Count 6
Contact Function ON-OFF
Washable Yes
Actuator Level Raised
Solderability WAVE
Washability SOLVENT
Dimensions
Length 0.393 10.00mm
Actuator Length 4.4mm
Height Above Board 0.394 10.00mm
Compliance
RoHS Status ROHS3 Compliant
