NDPL-10-V
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SWITCH DIL PIANO SPST 50MA 24V
PDF
/
Buying Options
Total Price: USD $0.72
Unit Price: USD $0.719483
≥1 USD $0.719483
≥10 USD $0.597825
≥100 USD $0.536342
Inventory: 7
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole, Right Angle
Body Material Polybutylene Terephthalate (PBT)
Technical
Operating Temperature -20°C~70°C
Packaging Tube
Series NDPL
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Positions 10
Voltage - Rated 24VDC
Current Rating (Amps) 25mA
Pitch 0.100 2.54mm Full
Contact Finish Gold
Termination Style PC Pin
Actuator Type Piano
Circuit SPST
Electrical Life 2,000 Cycles
Washable No
Actuator Level Raised
Dimensions
Length 1.050 26.67mm
Height Above Board 0.402 10.20mm
Compliance
RoHS Status ROHS3 Compliant
