NDIR04H
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Slide (Standard) NDI 4 Through Hole Dip Switch 0m 0.025A 500VDC V 50mOhm
PDF
/
Buying Options
Total Price: USD $4.2
Unit Price: USD $4.197341
≥1 USD $4.197341
≥210 USD $1.67526
≥504 USD $1.618806
≥1008 USD $1.591235
Inventory: 8695
Minimum: 1
-
+
Technical Details
Technical
HTS Code 8536.50.90.65
Current Rating (Amps) 25mA
Pitch 0.100 2.54mm Full
Orientation Straight
Terminal Pitch 2.54mm
Contact Finish Gold
Termination Style PC Pin
Body Breadth 6.6 mm
Actuator Type Slide (Standard)
Circuit SPST
Contact Resistance 50mOhm
Insulation Resistance 100000000Ohm
Contact Current(DC)-Max 0.025A
Sealing MOLDED
Dielectric Withstanding Voltage 500VDC V
Electrical Life 2,000 Cycles
Max Voltage Rating (DC) 24V
Mechanical Life 2,000 Cycles
Switch Type SLIDE DIP SWITCH
Number of Switch Sections 1
PCB Hole Count 8
Contact Function ON-OFF
Washable No
Actuator Level Flush, Recessed
Solderability WAVE
Body Color BLACK
Washability SOLVENT
Additional Feature RECESSED ACTUATOR
Voltage - Rated 24VDC
Number of Positions 4
ECCN Code EAR99
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series NDI
Packaging Tube
Operating Temperature -20°C~85°C
Dimensions
Length 0.437 11.10mm
Actuator Length 0m
Height Above Board 0.173 4.40mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Terminal Material BRASS
Actuator Material Nylon
Body Material Polybutylene Terephthalate (PBT), Glass Filled
Insulation Material GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Mounting Type Through Hole
Mount Through Hole
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 8 Weeks
