RLZTE-115.6A
RoHS
RoHS compliant
RoHS compliantPackage DO-213AC, MINI-MELF, SOD-80
Category Discrete Semiconductor Products / Diodes - Zener - Single
Description
DIODE ZENER 5.6V 500MW LLDS
PDF
/
Buying Options
Total Price: USD $1.41
Unit Price: USD $1.406
≥1 USD $1.406
≥10 USD $1.15425
≥100 USD $1.11815
≥500 USD $1.08205
≥1000 USD $1.04595
Inventory: 19508
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Reverse Current-Max 5μA
Working Test Current 20mA
Zener Voltage 5.6V
Voltage - Zener (Nom) (Vz) 5.6V
Reference Voltage 5.6V
Impedance-Max 13Ohm
Case Connection ISOLATED
Current - Reverse Leakage @ Vr 5μA @ 2.5V
Diode Type ZENER DIODE
Impedance 13Ohm
Configuration SINGLE
Polarity UNIDIRECTIONAL
Number of Elements 1
Operating Temperature (Max) 175°C
Qualification Status Not Qualified
JESD-30 Code O-LELF-R2
Reach Compliance Code unknown
Terminal Form WRAP AROUND
Terminal Position END
Technology ZENER
Max Power Dissipation 500mW
HTS Code 8541.10.00.50
Additional Feature HIGH RELIABILITY
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Tolerance ±3%
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Package / Case DO-213AC, MINI-MELF, SOD-80
Mounting Type Surface Mount
Mount Surface Mount
