CZRU52C2-HF
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, No Lead
Category Discrete Semiconductor Products / Diodes - Zener - Single
Description
DIODE ZENER 2V 150MW 0603
PDF
/
Buying Options
Total Price: USD $0.3
Unit Price: USD $0.2992
≥1 USD $0.2992
≥10 USD $0.20768
≥100 USD $0.104896
≥500 USD $0.085554
≥1000 USD $0.063474
≥3000 USD $0.053407
Inventory: 1234
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Working Test Current 5mA
Voltage Tol-Max 5%
Zener Voltage 2V
Voltage - Zener (Nom) (Vz) 2V
Reference Voltage 2V
Impedance-Max 100Ohm
Voltage - Forward (Vf) (Max) @ If 900mV @ 10mA
Current - Reverse Leakage @ Vr 100μA @ 1V
Diode Type ZENER DIODE
Element Configuration Single
Impedance 100Ohm
Number of Elements 1
Base Part Number CZRU52C2
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 260
Max Power Dissipation 150mW
Subcategory Voltage Reference Diodes
HTS Code 8541.10.00.50
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±5%
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Package / Case 2-SMD, No Lead
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
