MV104
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Diodes - Variable Capacitance (Varicaps, Varactors)
Description
DIODE TUNING FM DUAL 32V TO92
PDF
/
Inventory: 2789
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status CONSULT SALES OFFICE (Last Updated: 6 days ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Number of Pins 3
Diode Element Material SILICON
Technical
Operating Temperature 125°C TJ
Packaging Bulk
Published 2007
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Additional Feature 1% MATCHING GUARANTEED
HTS Code 8541.10.00.80
Capacitance 37pF
Subcategory Varactors
Voltage - Rated DC 32V
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) 240
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 3
Qualification Status Not Qualified
Number of Elements 2
Power Dissipation-Max 0.28W
Element Configuration Common Cathode
Diode Type 1 Pair Common Cathode
Breakdown Voltage 32V
Capacitance @ Vr, F 42pF @ 3V 1MHz
Reverse Voltage 32V
Diode Capacitance-Nom 39.5pF
Capacitance Ratio 2.8
Capacitance Ratio Condition C3/C30
Quality Factor-Min 100
Q @ Vr, F 140 @ 3V, 100MHz
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
