ZC832BTA
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Diodes - Variable Capacitance (Varicaps, Varactors)
Description
Diode VAR Cap Single 25V 20.9pF 3-Pin SOT-23 T/R
PDF
/
Inventory: 4985
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 1.4mm
Length 3.05mm
Height 1mm
Technical
Q @ Vr, F 200 @ 3V, 50MHz
Quality Factor-Min 200
Diode Cap Tolerance 5%
Capacitance Ratio Condition C2/C20
Capacitance Ratio 6.5
Diode Capacitance-Nom 22pF
Reverse Voltage (DC) 25V
Capacitance @ Vr, F 23.1pF @ 2V 1MHz
Forward Current 200mA
Diode Type Single
Number of Elements 1
Pin Count 3
Base Part Number ZC832B
Time@Peak Reflow Temperature-Max (s) 40
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Rated DC 25V
Subcategory Varactors
Capacitance 23.1pF
HTS Code 8541.10.00.80
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Termination Solder
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Diode Element Material SILICON
Weight 7.994566mg
Number of Pins 3
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Mount Surface Mount
