HSMS-2829-TR2G
RoHS
/
Package TO-253-4, TO-253AA
Category Discrete Semiconductor Products / Diodes - RF
Description
DIODE SCHOTTKY RF QD 15V SOT-143
PDF
/
Inventory: 8258
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Package / Case TO-253-4, TO-253AA
Number of Pins 4
Diode Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tape & Reel (TR)
Published 2014
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Capacitance 1pF
Subcategory Other Diodes
Voltage - Rated DC 15V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Current Rating 1A
Base Part Number HSMS-2829
Number of Elements 4
Max Current Rating 1A
Power Dissipation-Max 0.25W
Diode Type Schottky - Cross Over
Output Current 1A
Max Reverse Leakage Current 100nA
Breakdown Voltage 15V
Forward Voltage 500mV
Max Repetitive Reverse Voltage (Vrrm) 15V
Capacitance @ Vr, F 1pF @ 0V 1MHz
Reverse Test Voltage 1V
Frequency Band C B
Resistance @ If, F 12Ohm @ 5mA 1MHz
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
