HSMP-482B-TR2G

Broadcom Limited
RoHS
/
Package SC-70, SOT-323
Category Discrete Semiconductor Products / Diodes - RF
Description DIODE PIN RF PWR LIMITER SOT-323
PDF
/
Inventory: 5746
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No

Technical

Diode Forward Resistance-Max 0.6Ohm
Diode Res Test Current 10mA
Diode Capacitance-Max 1pF
Resistance @ If, F 600mOhm @ 10mA 100MHz
Diode Capacitance-Nom 0.75pF
Frequency Band L B
Reverse Voltage 20V
Capacitance @ Vr, F 0.75pF @ 20V 1MHz
Forward Current 1A
Output Current 1A
Diode Type PIN - Single
Element Configuration Common Anode
Max Current Rating 1A
Number of Elements 1
Base Part Number HSMP-482B
Current Rating 1A
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology POSITIVE-INTRINSIC-NEGATIVE
Voltage - Rated DC 50V
Subcategory PIN Diodes
HTS Code 8541.10.00.80
Additional Feature LOW DISTORTION
Terminal Finish Matte Tin (Sn)
Type Switch
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 3
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Obsolete
JESD-609 Code e3
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ

Physical

Diode Element Material SILICON
Number of Pins 3
Package / Case SC-70, SOT-323
Mount Surface Mount

Supply Chain

Factory Lead Time 6 Weeks
