HSMP-3862-TR2G
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Diodes - RF
Description
DIODE PIN GP 50V 1A SOT-23
PDF
/
Inventory: 6393
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Diode Forward Resistance-Max 22Ohm
Diode Res Test Frequency 100MHz
Diode Res Test Current 1mA
Minority Carrier Lifetime-Nom 0.5 μs
Resistance @ If, F 1.5Ohm @ 100mA 100MHz
Diode Capacitance-Nom 0.2pF
Recovery Time 80 ns
Reverse Voltage 50V
Capacitance @ Vr, F 0.2pF @ 50V 1MHz
Application ATTENUATOR; SWITCHING
Forward Current 1A
Output Current 1A
Diode Type PIN - 1 Pair Series Connection
Power Dissipation-Max 0.25W
Max Current Rating 1A
Configuration SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
Number of Elements 2
Base Part Number HSMP-3862
Current Rating 1A
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology POSITIVE-INTRINSIC-NEGATIVE
Voltage - Rated DC 50V
Subcategory PIN Diodes
HTS Code 8541.10.00.80
Additional Feature LOW DISTORTION
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-236-3, SC-59, SOT-23-3
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
