VS-HFA08TB120-N3
RoHS
RoHS compliant
RoHS compliantPackage TO-220-2
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Diode Switching 1.2KV 8A 2-Pin(2+Tab) TO-220AC Tube
PDF
/
Inventory: 6300
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-2
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tube
Published 2016
Series HEXFRED?
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Additional Feature LOW NOISE, PD-CASE
HTS Code 8541.10.00.80
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Elements 1
Power Dissipation-Max 73.5W
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 10μA @ 1200V
Voltage - Forward (Vf) (Max) @ If 3.3V @ 8A
Case Connection CATHODE
Operating Temperature - Junction -55°C~150°C
Output Current-Max 8A
Application EFFICIENCY
Voltage - DC Reverse (Vr) (Max) 1200V
Forward Voltage 4.3V
Max Reverse Voltage (DC) 1.2kV
Average Rectified Current 8A
Number of Phases 1
Reverse Recovery Time 95 ns
Peak Non-Repetitive Surge Current 130A
Reverse Current-Max 10μA
Compliance
RoHS Status ROHS3 Compliant
