D121N18B
RoHS
/
Package /
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
PDF
/
Inventory: 1607
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Stud
Number of Pins 4
Diode Element Material SILICON
Technical
Published 1998
Part Status Active
Number of Terminations 1
Max Operating Temperature 180°C
Min Operating Temperature -40°C
Subcategory Rectifier Diodes
Terminal Position UPPER
Terminal Form HIGH CURRENT CABLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code O-XUPM-H1
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Diode Type RECTIFIER DIODE
Case Connection ANODE
Max Surge Current 3.1kA
Output Current-Max 230A
Application POWER
Halogen Free Halogen Free
Number of Phases 1
Peak Reverse Current 20mA
Max Repetitive Reverse Voltage (Vrrm) 1.6kV
Peak Non-Repetitive Surge Current 3.1kA
Non-rep Pk Forward Current-Max 2600A
Reverse Voltage 1.8kV
Max Forward Surge Current (Ifsm) 2.6kA
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
