VS-1N3892R
RoHS
RoHS compliant
RoHS compliantPackage DO-203AA, DO-4, Stud
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 300V 12A DO203AA
PDF
/
Inventory: 3162
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Chassis, Stud
Mounting Type Chassis, Stud Mount
Package / Case DO-203AA, DO-4, Stud
Diode Element Material SILICON
Technical
Packaging Bulk
Published 2017
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 1
ECCN Code EAR99
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Additional Feature FREE WHEELING DIODE
HTS Code 8541.10.00.80
Terminal Position UPPER
Terminal Form SOLDER LUG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 1N3892
JESD-30 Code O-MUPM-D1
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard, Reverse Polarity
Current - Reverse Leakage @ Vr 25μA @ 300V
Voltage - Forward (Vf) (Max) @ If 1.4V @ 12A
Operating Temperature - Junction -65°C~150°C
Max Surge Current 180A
Max Reverse Voltage (DC) 300V
Average Rectified Current 12A
Number of Phases 1
Reverse Recovery Time 300 ns
Peak Reverse Current 25μA
Reverse Voltage 300V
Recovery Time 300 ns
Natural Thermal Resistance 0.5 °C/W
Compliance
RoHS Status ROHS3 Compliant
