UGF12HT-E3/45
RoHS
RoHS compliant
RoHS compliantPackage TO-220-2 Full Pack, Isolated Tab
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 500V 12A ITO220AC
PDF
/
Inventory: 6610
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-2 Full Pack, Isolated Tab
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tube
Published 2011
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Additional Feature FREE WHEELING DIODE
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Pin Count 3
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 30μA @ 500V
Voltage - Forward (Vf) (Max) @ If 1.75V @ 12A
Forward Current 12A
Operating Temperature - Junction -55°C~150°C
Max Surge Current 135A
Application EFFICIENCY
Max Reverse Voltage (DC) 500V
Average Rectified Current 12A
Number of Phases 1
Reverse Recovery Time 50 ns
Peak Reverse Current 30μA
Max Repetitive Reverse Voltage (Vrrm) 500V
Peak Non-Repetitive Surge Current 135A
Reverse Voltage 500V
Recovery Time 50 ns
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
