MBRB10H60HE3/81
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Tape & Reel (TR) Surface Mount Schottky Common Cathode Diode Schottky 710mV @ 10A 10A 850mV 175C
PDF
/
Buying Options
Total Price: USD $12.04
Unit Price: USD $12.04125
≥1 USD $12.04125
≥10 USD $9.88
≥100 USD $9.57125
≥500 USD $9.2625
≥1000 USD $8.95375
Inventory: 7404
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Published 2011
JESD-609 Code e3
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Additional Feature FREE WHEELING DIODE, HIGH RELIABILITY, LOW LEAKAGE CURRENT, LOW POWER LOSS
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Position SINGLE
Terminal Form GULL WING
Base Part Number MBRB10H60
Pin Count 3
JESD-30 Code R-PSSO-G2
Number of Elements 1
Element Configuration Common Cathode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 100μA @ 60V
Voltage - Forward (Vf) (Max) @ If 710mV @ 10A
Forward Current 10A
Max Reverse Leakage Current 100μA
Operating Temperature - Junction -65°C~175°C
Max Surge Current 150A
Application EFFICIENCY
Forward Voltage 850mV
Max Reverse Voltage (DC) 60V
Average Rectified Current 10A
Number of Phases 1
Peak Reverse Current 100μA
Max Repetitive Reverse Voltage (Vrrm) 60V
Peak Non-Repetitive Surge Current 150A
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
