STTH30R04WY
RoHS
RoHS compliant
RoHS compliantPackage DO-247-2 (Straight Leads)
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 400V 30A DO247
PDF
/
Inventory: 8744
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case DO-247-2 (Straight Leads)
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tube
Series Automotive, AEC-Q101
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 175°C
Min Operating Temperature -40°C
Additional Feature LOW LEAKAGE CURRENT
Base Part Number STTH30
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 15μA @ 400V
Voltage - Forward (Vf) (Max) @ If 1.55V @ 30A
Forward Current 30A
Operating Temperature - Junction -40°C~175°C
Max Surge Current 280A
Application ULTRA FAST RECOVERY
Forward Voltage 1.55V
Max Reverse Voltage (DC) 400V
Average Rectified Current 30A
Number of Phases 1
Reverse Recovery Time 100 ns
Peak Reverse Current 15μA
Max Repetitive Reverse Voltage (Vrrm) 400V
Peak Non-Repetitive Surge Current 280A
Recovery Time 24 ns
Reverse Voltage (DC) 400V
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
