STTH3002PI
RoHS
RoHS compliant
RoHS compliantPackage DOP3I-2 Insulated (Straight Leads)
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 200V 30A DOP3I
PDF
/
Inventory: 1624
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case DOP3I-2 Insulated (Straight Leads)
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Additional Feature FREE WHEELING DIODE
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Base Part Number STTH30
Pin Count 2
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 20μA @ 200V
Voltage - Forward (Vf) (Max) @ If 1.05V @ 30A
Forward Current 30A
Operating Temperature - Junction 175°C Max
Max Surge Current 300A
Application ULTRA FAST RECOVERY
Forward Voltage 1.05V
Max Reverse Voltage (DC) 200V
Average Rectified Current 30A
Number of Phases 1
Reverse Recovery Time 50 ns
Peak Reverse Current 20μA
Max Repetitive Reverse Voltage (Vrrm) 200V
Peak Non-Repetitive Surge Current 300A
Reverse Voltage 200V
Recovery Time 50 ns
Dimensions
Height 21.1mm
Length 15.5mm
Width 4.6mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
