STTH2002D
RoHS
RoHS compliant
RoHS compliantPackage TO-220-2
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
STTH2002 Series 200 V 20 A Through Hole Ultrafast Recovery Diode - TO-220AC
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5529
≥1 USD $0.5529
≥10 USD $0.4541
≥100 USD $0.43985
≥500 USD $0.4256
≥1000 USD $0.41135
Inventory: 1858
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-2
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Additional Feature FREE WHEELING DIODE
HTS Code 8541.10.00.80
Capacitance 7pF
Subcategory Rectifier Diodes
Voltage - Rated DC 200V
Current Rating 20A
Base Part Number STTH2
Pin Count 3
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 10μA @ 200V
Output Current 20A
Voltage - Forward (Vf) (Max) @ If 1.1V @ 20A
Case Connection CATHODE
Forward Current 20A
Operating Temperature - Junction 175°C Max
Max Surge Current 175A
Application ULTRA FAST RECOVERY
Forward Voltage 1.1V
Max Reverse Voltage (DC) 200V
Average Rectified Current 20A
Number of Phases 1
Reverse Recovery Time 40 ns
Peak Reverse Current 10μA
Max Repetitive Reverse Voltage (Vrrm) 200V
Peak Non-Repetitive Surge Current 175A
Reverse Voltage 200V
Max Forward Surge Current (Ifsm) 175A
Recovery Time 40 ns
Dimensions
Height 15.75mm
Length 10.4mm
Width 4.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
