STTH1R06UFY
RoHS
RoHS compliant
RoHS compliantPackage DO-221AA, SMB Flat Leads
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
STMICROELECTRONICS STTH1R06UFY Standard Recovery Diode, Single, 600 V, 1 A, 1.9 V, 45 ns, 17 A
PDF
/
Buying Options
Total Price: USD $0.53
Unit Price: USD $0.528
≥1 USD $0.528
≥10 USD $0.4532
≥100 USD $0.315216
≥500 USD $0.246101
≥1000 USD $0.200033
≥3000 USD $0.178816
Inventory: 1443
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Max Forward Surge Current (Ifsm) 17A
Max Repetitive Reverse Voltage (Vrrm) 600V
Reverse Recovery Time 45 ns
Average Rectified Current 1A
Max Reverse Voltage (DC) 600V
Forward Voltage 1.9V
Output Current-Max 1A
Operating Temperature - Junction -40°C~175°C
Forward Current 1A
Voltage - Forward (Vf) (Max) @ If 1.9V @ 1A
Current - Reverse Leakage @ Vr 1μA @ 600V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Base Part Number STTH1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Max Operating Temperature 175°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101
Packaging Cut Tape (CT)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-221AA, SMB Flat Leads
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 8 Weeks
