STTH1R02QRL
RoHS
RoHS compliant
RoHS compliantPackage DO-204AC, DO-15, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 200V 1.5A DO15
PDF
/
Buying Options
Total Price: USD $0.33
Unit Price: USD $0.3344
≥1 USD $0.3344
≥10 USD $0.23584
≥100 USD $0.1188
≥500 USD $0.105301
≥1000 USD $0.081946
≥3000 USD $0.073348
Inventory: 2001
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3.53mm
Length 6.75mm
Height 3.53mm
Technical
Recovery Time 30 ns
Max Forward Surge Current (Ifsm) 60A
Reverse Voltage 200V
Peak Non-Repetitive Surge Current 60A
Max Repetitive Reverse Voltage (Vrrm) 200V
Peak Reverse Current 3μA
Reverse Recovery Time 30 ns
Number of Phases 1
Average Rectified Current 1.5A
Max Reverse Voltage (DC) 200V
Forward Voltage 1.2V
Application ULTRA FAST RECOVERY
Max Surge Current 60A
Operating Temperature - Junction 175°C Max
Forward Current 1.5A
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1V @ 1.5A
Current - Reverse Leakage @ Vr 3μA @ 200V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Pin Count 2
Base Part Number STTH1
Terminal Form WIRE
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Terminal Finish MATTE TIN
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-204AC, DO-15, Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 8 Weeks
