STPS30SM100SR
RoHS
RoHS compliant
RoHS compliantPackage TO-262-3 Long Leads, I2Pak, TO-262AA
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 100V 30A I2PAK
PDF
/
Buying Options
Total Price: USD $2.07
Unit Price: USD $2.068
≥1 USD $2.068
≥10 USD $1.659856
≥100 USD $1.36576
Inventory: 270
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-262-3 Long Leads, I2Pak, TO-262AA
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tube
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 3
ECCN Code EAR99
Max Operating Temperature 150°C
Min Operating Temperature -65°C
HTS Code 8541.10.00.80
Terminal Position SINGLE
Base Part Number STPS30
Pin Count 3
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Common Anode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 45μA @ 100V
Voltage - Forward (Vf) (Max) @ If 870mV @ 30A
Case Connection CATHODE
Forward Current 30A
Max Reverse Leakage Current 45μA
Operating Temperature - Junction 150°C Max
Max Surge Current 530A
Application EFFICIENCY
Forward Voltage 870mV
Max Reverse Voltage (DC) 100V
Average Rectified Current 30A
Number of Phases 1
Peak Reverse Current 45μA
Max Repetitive Reverse Voltage (Vrrm) 100V
Peak Non-Repetitive Surge Current 530A
Max Forward Surge Current (Ifsm) 530A
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
