STPS2200UF
RoHS
RoHS compliant
RoHS compliantPackage DO-221AA, SMB Flat Leads
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 200V 2A SMBFLAT
PDF
/
Buying Options
Total Price: USD $0.93
Unit Price: USD $0.9328
≥1 USD $0.9328
≥10 USD $0.76032
≥100 USD $0.591712
≥500 USD $0.501512
≥1000 USD $0.40854
≥3000 USD $0.384586
Inventory: 1337
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.95mm
Length 4.6mm
Height 1.1mm
Technical
Max Forward Surge Current (Ifsm) 100A
Peak Non-Repetitive Surge Current 100A
Max Repetitive Reverse Voltage (Vrrm) 200V
Peak Reverse Current 5μA
Number of Phases 1
Average Rectified Current 2A
Max Reverse Voltage (DC) 200V
Forward Voltage 800mV
Application FAST RECOVERY POWER
Max Surge Current 100A
Operating Temperature - Junction -40°C~175°C
Max Reverse Leakage Current 2.5mA
Forward Current 2A
Voltage - Forward (Vf) (Max) @ If 800mV @ 2A
Current - Reverse Leakage @ Vr 5μA @ 200V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Base Part Number STPS2200
Terminal Position DUAL
Additional Feature FREE WHEELING DIODE
Min Operating Temperature -40°C
Max Operating Temperature 175°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-221AA, SMB Flat Leads
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 weeks ago)
Factory Lead Time 8 Weeks
