STPS20SM120STN
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
STMICROELECTRONICS STPS20SM120STN DIODE, SCHOTTKY, 20A, 120V ,POWERFLAT
PDF
/
Buying Options
Total Price: USD $1.41
Unit Price: USD $1.408
≥1 USD $1.408
≥10 USD $1.130624
≥100 USD $0.895928
≥500 USD $0.759387
≥1000 USD $0.618605
Inventory: 1093
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Natural Thermal Resistance 1.55 °C/W
Max Forward Surge Current (Ifsm) 220A
Peak Non-Repetitive Surge Current 220A
JEDEC-95 Code TO-220AB
Max Repetitive Reverse Voltage (Vrrm) 120V
Peak Reverse Current 210μA
Number of Phases 1
Average Rectified Current 20A
Max Reverse Voltage (DC) 120V
Forward Voltage 890mV
Application EFFICIENCY
Operating Temperature - Junction 150°C Max
Forward Current 20A
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 890mV @ 20A
Current - Reverse Leakage @ Vr 210μA @ 120V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Base Part Number STPS20
Reach Compliance Code not_compliant
Subcategory Rectifier Diodes
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
JESD-609 Code e3
Series ECOPACK?2
Packaging Tube
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Alternative Model
