STPS1L60ZFY
RoHS
RoHS compliant
RoHS compliantPackage SOD-123F
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 60V 1A SOD123F
PDF
/
Buying Options
Total Price: USD $0.35
Unit Price: USD $0.352
≥1 USD $0.352
≥10 USD $0.24992
≥100 USD $0.126016
≥500 USD $0.11169
≥1000 USD $0.086926
Inventory: 71674
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case SOD-123F
Surface Mount YES
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q101
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Additional Feature FREE WHEELING
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STPS1
JESD-30 Code R-PDSO-F2
Operating Temperature (Max) 175°C
Number of Elements 1
Configuration SINGLE
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 50μA @ 60V
Voltage - Forward (Vf) (Max) @ If 570mV @ 1A
Forward Current 1A
Operating Temperature - Junction -40°C~175°C
Output Current-Max 1A
Voltage - DC Reverse (Vr) (Max) 60V
Rep Pk Reverse Voltage-Max 60V
Compliance
RoHS Status ROHS3 Compliant
