STPS120MF
RoHS
RoHS compliant
RoHS compliantPackage DO-222AA
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 20V 1A STMITEFLAT
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.4048
≥1 USD $0.4048
≥10 USD $0.28952
≥100 USD $0.145992
≥500 USD $0.129378
≥1000 USD $0.100681
≥3000 USD $0.090112
Inventory: 21402
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Peak Non-Repetitive Surge Current 50A
Max Repetitive Reverse Voltage (Vrrm) 20V
Peak Reverse Current 3.9μA
Average Rectified Current 1A
Max Reverse Voltage (DC) 20V
Forward Voltage 440mV
Output Current-Max 1A
Max Surge Current 50A
Operating Temperature - Junction 150°C Max
Max Reverse Leakage Current 300μA
Forward Current 1A
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 490mV @ 1A
Current - Reverse Leakage @ Vr 3.9μA @ 20V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Pin Count 3
Base Part Number STPS120
Terminal Form FLAT
Terminal Position DUAL
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Min Operating Temperature -65°C
Max Operating Temperature 150°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Cut Tape (CT)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-222AA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 6 Weeks
