1N5822
RoHS
RoHS compliant
RoHS compliantPackage DO-201AD, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 40V 3A DO201AD
PDF
/
Buying Options
Total Price: USD $0.41
Unit Price: USD $0.4136
≥1 USD $0.4136
≥10 USD $0.33704
≥100 USD $0.308352
≥500 USD $0.229504
≥1000 USD $0.207997
≥3000 USD $0.172146
Inventory: 1155
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 5.3mm
Length 9.5mm
Height 5.3mm
Technical
Max Junction Temperature (Tj) 150°C
Max Forward Surge Current (Ifsm) 80A
Peak Non-Repetitive Surge Current 80A
Max Repetitive Reverse Voltage (Vrrm) 40V
Peak Reverse Current 2mA
Number of Phases 1
Average Rectified Current 3A
Max Reverse Voltage (DC) 40V
Forward Voltage 525mV
Application POWER
Max Surge Current 80A
Operating Temperature - Junction 150°C Max
Max Reverse Leakage Current 2mA
Forward Current 3A
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 525mV @ 3A
Output Current 3A
Current - Reverse Leakage @ Vr 2mA @ 40V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Polarity Standard
Number of Elements 1
Pin Count 2
Base Part Number 1N58
Current Rating 3A
Terminal Form WIRE
Voltage - Rated DC 40V
Subcategory Rectifier Diodes
Capacitance 190pF
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Box (TB)
Physical
Diode Element Material SILICON
Weight 4.535924g
Number of Pins 2
Package / Case DO-201AD, Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 6 Weeks
