1N5817RL
RoHS
RoHS compliant
RoHS compliantPackage DO-204AL, DO-41, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Tape & Reel (TR) Through Hole Schottky Single Diode Schottky 450mV @ 1A 1A 450mV 150C
PDF
/
Buying Options
Total Price: USD $0.09
Unit Price: USD $0.09405
≥1 USD $0.09405
≥10 USD $0.0779
≥100 USD $0.07505
≥500 USD $0.07315
≥1000 USD $0.0703
Inventory: 16051
Minimum: 1
-
+
Technical Details
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Package / Case DO-204AL, DO-41, Axial
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Additional Feature FREE WHEELING DIODE
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 40V
Terminal Form WIRE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Current Rating 1A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 1N58
Pin Count 2
Qualification Status Not Qualified
Number of Elements 1
Polarity Standard
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 500μA @ 20V
Output Current 1A
Voltage - Forward (Vf) (Max) @ If 450mV @ 1A
Case Connection ISOLATED
Forward Current 1A
Max Reverse Leakage Current 500μA
Operating Temperature - Junction 150°C Max
Max Surge Current 25A
Forward Voltage 450mV
Max Reverse Voltage (DC) 20V
Average Rectified Current 1A
Peak Reverse Current 500μA
Max Repetitive Reverse Voltage (Vrrm) 20V
Peak Non-Repetitive Surge Current 25A
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
