ER303-AP
RoHS
RoHS compliant
RoHS compliantPackage DO-201AD, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 300V 3A DO201AD
PDF
/
Inventory: 5004
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case DO-201AD, Axial
Surface Mount NO
Diode Element Material SILICON
Technical
Packaging Tape & Box (TB)
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature LOW LEAKAGE CURRENT
HTS Code 8541.10.00.80
Terminal Form WIRE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 2
JESD-30 Code O-PALF-W2
Qualification Status Not Qualified
Number of Elements 1
Configuration SINGLE
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Voltage - Forward (Vf) (Max) @ If 1.25V @ 40V
Case Connection ISOLATED
Operating Temperature - Junction -55°C~150°C
Output Current-Max 3A
Application SUPER FAST RECOVERY
Voltage - DC Reverse (Vr) (Max) 300V
Current - Average Rectified (Io) 3A
Number of Phases 1
Reverse Recovery Time 35ns
Rep Pk Reverse Voltage-Max 300V
Capacitance @ Vr, F 35pF @ 4V 1MHz
Non-rep Pk Forward Current-Max 125A
Compliance
RoHS Status RoHS Compliant
