1N5408-TP
RoHS
RoHS compliant
RoHS compliantPackage DO-201AD, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 1KV 3A DO201AD
PDF
/
Buying Options
Total Price: USD $0.31
Unit Price: USD $0.308996
≥1 USD $0.308996
≥10 USD $0.291511
≥100 USD $0.275003
≥500 USD $0.259432
≥1000 USD $0.244759
Inventory: 1121
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Through Hole
Package / Case DO-201AD, Axial
Surface Mount NO
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Published 1996
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature LOW LEAKAGE CURRENT
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Form WIRE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 1N5408
Pin Count 2
JESD-30 Code O-PALF-W2
Qualification Status Not Qualified
Operating Temperature (Max) 150°C
Number of Elements 1
Configuration SINGLE
Speed Standard Recovery >500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 5μA @ 1000V
Voltage - Forward (Vf) (Max) @ If 1V @ 3A
Case Connection ISOLATED
Operating Temperature - Junction -55°C~150°C
Output Current-Max 3A
Application GENERAL PURPOSE
Voltage - DC Reverse (Vr) (Max) 1000V
Current - Average Rectified (Io) 3A
Number of Phases 1
Rep Pk Reverse Voltage-Max 1000V
Capacitance @ Vr, F 40pF @ 4V 1MHz
Non-rep Pk Forward Current-Max 200A
Compliance
RoHS Status RoHS Compliant
