DSEP60-12B
RoHS
/
Package TO-247-2
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
POWER DIODE DISCRETES-FRED TO-24
PDF
/
Buying Options
Total Price: USD $8.65
Unit Price: USD $8.6504
≥1 USD $8.6504
≥10 USD $6.90272
≥100 USD $6.17606
≥500 USD $5.449462
≥1000 USD $4.904504
Inventory: 128
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mounting Type Through Hole
Package / Case TO-247-2
Surface Mount NO
Diode Element Material SILICON
Technical
Packaging Tube
Part Status Active
Number of Terminations 2
ECCN Code EAR99
Additional Feature FREE WHEELING DIODE, LOW LEAKAGE CURRENT, SNUBBER DIODE
Technology AVALANCHE
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reference Standard IEC-60747
JESD-30 Code R-PSFM-T2
Operating Temperature (Max) 175°C
Number of Elements 1
Configuration SINGLE
Power Dissipation-Max 330W
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 200μA @ 1200V
Voltage - Forward (Vf) (Max) @ If 3.25V @ 60A
Case Connection CATHODE
Operating Temperature - Junction -55°C~175°C
Application FAST SOFT RECOVERY
Voltage - DC Reverse (Vr) (Max) 1200V
Current - Average Rectified (Io) 60A
Number of Phases 1
Reverse Recovery Time 65ns
Rep Pk Reverse Voltage-Max 1200V
Capacitance @ Vr, F 30pF @ 600V 1MHz
Non-rep Pk Forward Current-Max 500A
Reverse Current-Max 200μA
