DLA20IM800PC-TUB
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Bridge Rectifiers Single Diode
PDF
/
Buying Options
Total Price: USD $2.57
Unit Price: USD $2.5696
≥1 USD $2.5696
≥10 USD $2.067296
≥100 USD $1.700952
≥500 USD $1.43924
≥1000 USD $1.221176
≥3000 USD $1.160122
Inventory: 1053
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Natural Thermal Resistance 0.25 °C/W
Reverse Current-Max 5μA
Non-rep Pk Forward Current-Max 185A
Capacitance @ Vr, F 4pF @ 400V 1MHz
Number of Phases 1
Average Rectified Current 20A
Max Reverse Voltage (DC) 800V
Voltage - DC Reverse (Vr) (Max) 800V
Application EFFICIENCY
Operating Temperature - Junction -55°C~175°C
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 1.2V @ 20A
Current - Reverse Leakage @ Vr 10μA @ 800V
Diode Type Standard
Speed Standard Recovery >500ns, > 200mA (Io)
Power Dissipation-Max 150W
Configuration SINGLE
Number of Elements 1
Operating Temperature (Max) 175°C
JESD-30 Code R-PSSO-G2
Reference Standard IEC-60747
Terminal Form GULL WING
Terminal Position SINGLE
Additional Feature LOW LEAKAGE CURRENT, PD-CASE
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2014
Packaging Tube
Physical
Diode Element Material SILICON
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Mount Surface Mount
