SD945-T
RoHS
RoHS compliant
RoHS compliantPackage DO-201AD, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 45V 9A DO201AD
PDF
/
Inventory: 2583
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 5.3mm
Length 9.5mm
Height 5.3mm
Technical
Max Forward Surge Current (Ifsm) 2.15kA
Peak Non-Repetitive Surge Current 2.15kA
Capacitance @ Vr, F 900pF @ 4V 1MHz
Max Repetitive Reverse Voltage (Vrrm) 45V
Peak Reverse Current 800μA
Reverse Recovery Time 150 ns
Number of Phases 1
Average Rectified Current 9A
Max Reverse Voltage (DC) 45V
Forward Voltage 570mV
Application EFFICIENCY
Output Current-Max 9A
Operating Temperature - Junction -65°C~150°C
Forward Current 9A
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 570mV @ 18A
Current - Reverse Leakage @ Vr 800μA @ 45V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Pin Count 2
Base Part Number SD945
Time@Peak Reflow Temperature-Max (s) 40
Peak Reflow Temperature (Cel) 260
Terminal Form WIRE
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature LOW POWER LOSS, HIGH SURGE CAPABILITY
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2008
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Weight 1.09999g
Number of Pins 2
Package / Case DO-201AD, Axial
Mounting Type Through Hole
Mount Through Hole
